Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Sensor | Impinj R2000 RF |
|---|---|
| Air Interface Protocol | EPC global UHF Class 1 Gen 2/ISO 18000-6C |
| Working frequency | 840～960MHz（Default frequency band 920～925MHz） |
| support areas | China, Europe, United States, South Korea, Japan, Taiwan…… |
| Working voltage | DC3.0-6.0V |
| Peak operating current | 1.5A | ≤50mA |
| Sleep current | ≤1mA |
| Maximum output power of RF port | 1W(30dBm) |
| Work Temperature | -25℃～+65℃ |
| Working humidity | ≤95%（+25℃） |
| Storage temperature | -30℃～+70℃ |
| Maximum receiving sensitivity | -82dBm |
| Antenna interface impedance | 50Ω |
| Serial communication parameters | Baud rate adjustable (default 115200bps), parity bit: none, data bit: 8, stop bit: 1 |
|---|---|
| Power output setting | 5-30dBm adjustable/adjustable minimum interval is 1dBm (default 30dBm) |
| DRM mode | Support |
| RSSI | Support |
| High temperature automatic protection function | Support |
| Power Enable | Support |
| GPIO Interface | Support |
| Antenna interface | 16 SMA female heads |
| FPC interface | 10PIN/1.0mm/top connection |
| SIZE | 165.4*79.6*6.5MM |
