Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Sensor | Impinj R2000 |
|---|---|
| Working Voltage | DC 3.7～5V |
| Working Current | 1.5A |
| Standby Current | ≤50mA |
| Sleep Current | ≤1mA |
| Working Temperature | -25～+65℃ |
| Working Humidity | -40～+80℃ |
| Storage Temperature | 1W(30dBm) |
| Tag Protocol | EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C |
| Working Frequency | 840～960 MHz |
| Supporting Working Areas | China 1，China 2，US, Canada and other regions following U.S. FCC.Europe and other regions following ETSI EN 302 208 with & without LBT regulations Japan，Korea，Malaysia，Taiwan |
| Output Power | Software adjustable, step interval 1.0dB, maximum 30dBm |
| Output Power Flatness | ±0.2dBm |
| Receiving Sensitivity | -82dBm |
| RF Port Standing Wave | ≤1.5 |
|---|---|
| Reading Distance | ≥10m（With 8dBi antenna/Relate to tags type, transmitted power and application environment） |
| Multi-tag Reading | ≥400 tags/s |
| Antenna Interface Amount | one（MMCX） |
| Interface Communication Rate | 115200bps |
| Working Temprature Detection | Support |
| Intensive Read /Write Mode DRM | Support |
| Antenna Connection Protection | Support |
| RSSI | Support |
| LED | Red light (power indicator ) |
| Product Cooling Way | Aluminum metal case as cooling fin for the module |
| Dimension | 56.5*36.0*7.8 MM |
