Features
.png)
Strong Stability
Functions
.png)
UHF RFID(PHYCHIPS PR9200Chip)
Technical Parameters
| Sensor | Impinj R2000 |
|---|---|
| Air Interface Protocol | EPC global UHF Class 1 Gen 2/ISO 18000-6C |
| Working frequency | 840～960MHz（Default frequency band 920～925MHz） |
| Support Regions | China, Europe, the United States, South Korea, Japan, Taiwan…… |
| Operating Voltage | DC3.0-6.0V |
| Peak operating current | 1.5A |
| Stand-by current | ≤50mA |
| Sleep current | ≤1mA |
| Maximum output power of RF port | 1W(30dBm) |
| Working temperature | -25℃～+65℃ |
| Working humidity | ≤95%（+25℃） |
| Storage temperature | -30℃～+70℃ |
| Maximum receiving sensitivity | -82dBm |
| Antenna interface impedance | 50Ω |
|---|---|
| Serial communication parameters | Baud rate adjustable (default 115200bps), parity bit: none, data bit: 8 bits, stop bit: 1 bit |
| Power output setting | 5～30dBm adjustable/minimum adjustable interval is 1dBm (default 30dBm) |
| DRM mode | Support |
| RSSI | Support |
| High temperature automatic protection function | Support |
| Power Enable | Support |
| GPIO interface | Support |
| Antenna interface | 8 SMA female connectors |
| FPC interface | 10PIN/1.0mm/upper connection |
| Size | 165.4*79.6*6.5MM |
