Features
.png)
Strong Stability
.png)
Outstanding Consistency
Functions
.png)
UHF RFID(Impinj R2000 Chip)
.png)
Barcode Scanning(Optional)
.png)
NFC(Optional)
.png)
GPS
Technical Parameters
| Sensor | ARM-COTEXM3 |
|---|---|
| Air Interface Protocol | EPC global UHF Class 1 Gen 2/ISO 18000-6C |
| Working Frequency | 840～960MHz（ Default frequency band 920～925MHz） |
| Support Area | China, Europe, United States, South Korea, Japan …… |
| Working Voltage | DC12V |
| Working current | ＜2.5A |
| Standby current | ＜50mA |
| Output power | Software adjustable: Step interval of 1.0dB,+5dBm~33dBm (adjustable separately for each channel) |
| Maximum receiving sensitivity | -82dBm |
| Working Temperature | -25℃～+65℃ |
| Working humidity | ≤95%（+25℃） |
| Storage temperature | -30℃～+70℃ |
| DRM mode | Support |
| RSSI | support |
|---|---|
| High temperature automatic protection | support |
| External watchdog | support |
| Network disconnection alarm | support |
| Disconnect and reconnect from the internet | support |
| GPIO port | Input IO port: 2 channels Output IO port: 4 channels |
| Buzzer | Support |
| LED indicator light | Power indicator light: 1 LED (red) Status indicator light: 1 LED (green) |
| Communication function | Mini USB interface, Ethernet port, RS-485 WIFI (optional), Bluetooth (customizable) |
| Antenna interface | 16 PCS SMA |
| Dimension | 165*135*27mm |
