Performance
| size | 208mm×125mm×35mm(L×W×H) |
|---|---|
| Weight | 0.75kg |
| Power Consumption | 12W |
| power | DC12V |
| Installation method | Installation of clamps |
| operation temperature | -40℃~70℃ |
| storage temperature | -50℃~80℃ |
| Working humidity | 5%～95%～（No condensation） |
| IP lever | IP65 |
Communication
| communication interface | RS232、RS485、Wiegand 26 / 34,10 / 100M adaptive Ethernet interface |
|---|---|
| I/O interface | 2-channel input interface, 4-channel output interface (optional) |
| Scalable wireless module | 802.11 module, the whole network through the 4G module |
| UPGRADE | Support serial upgrade |
| Serial communication parameters | Adjustable baud rate (default 230400bps) |
| Application software platform | Provide software development kit (SDK) and API |
Label operation
| tag operation support | proprietary protocol |
|---|---|
| Support tag work mode | Active tags |
| Read tag distance | 5～350m （Depends on the output power of the antenna and tag） |
| Recognition speed | 500 tags per second (ID number only) |
Operating
| Working Frequency | 2.4~2.483G |
|---|---|
| Output power | Software adjustable: 0-63dbm (the larger the value, the greater the attenuation) |
| Receiver sensitivity | -95dBm |
| Communication speed | 1Mbit/s |
| Antenna gain | 12dBi |
| Identify angles | directional（Hor:33°/ Ver:36°） |
| Polarization mode | Vertical polarization |
