Features
2.45G
IP65 Sealing
7.6V4000mAh
Physical
Tag characteristics | Thin type |
---|---|
Sensing mode | Active launch once per second |
Material | ABS,White |
Size | 86*55*4mm |
Industrial grade | IP67 |
Installation method | Carry |
2.4G
Signal modulation | GFSK |
---|---|
Communication rate | 1Mbit/s |
Output Power | 7dbm |
Electrical
Quiescent Current | 3uA |
---|---|
Peak current | 《25mA |
Average current | 《20uA |
Battery model | CR3032 |
Battery capacity | 500mA |
Service life | More than two years |
Environmental
Operating temperature | -20℃~+45℃ |
---|---|
Storage temperature | -30℃~+65℃ |
